Compact LED and Class 3R laser multi-effect fixture - JB SYSTEMS BEG-B04176

JB Systems BEG-B04176 is a compact multi-effect fixture combining a total LED power of 23 W with a 200 mW red/green laser in one unit. It integrates three effects: five 3 W LEDs in red, green, blue, orange and white; a strobe section with eight 1 W white LEDs; and laser effects using a 150 mW red laser and a 50 mW green laser, Class 3R. DMX control can use 1 channel for straightforward operation or 9 channels for full control. Stand-alone operation offers sound activation through the internal microphone or automatic mode, while Master/Slave operation creates synchronised shows. A 3-digit LED display makes menu navigation simple. IEC power input and output facilitate connection. Safety features include a key-operated ON/OFF switch and an emergency-switch input with interlock. The fixture complies with EN/IEC 60825-1 2007 for laser safety.

Specifications:

• Power input: 100 - 240 V AC, 50/60 Hz
• Power consumption: 66 W
• Colour: black
• Display: LED
• Fixation: optional standard clamp
• IP rating: indoor
• Master/Slave: yes
• Stand-alone modes: automatic, sound
• Maximum DMX channels: 9
• Lamp: LED
• Colours: red, green, blue, white and other
• Output connections: 3-pin XLR, IEC
• Dimensions: 24 x 22 x 11 cm
• Weight: 3.75 kg
