Passive 2-way column loudspeaker C5CX - HARMONIC DESIGN HDE-40360

Compact 2-way, 5-speaker passive stick loudspeaker featuring 4 x 3" mid-woofers and a 3.5" coaxial speaker with a 1" tweeter with an extended, linear frequency response. It works with any power amplifier, without DSP, making the hd C5CX the optimal solution for decentralized audio applications or environments such as restaurants, conference rooms or theaters.The hd C5CX can be installed with great ease and flexibility permanently or moved as needed for mobile use. Using the discreet wall mount with ball joint, the loudspeaker can be easily angled or discreetly fixed very close to the surface with the L-angle wall mount. Internal terminal block connections ensure quick and tool-free connection of the loudspeaker. hd C5CX can be customized in all RAL colors and special lengths for optimal adaptation to the room architecture. If wall mounting is not possible, the loudspeakers can be used with the threaded base plate from 3/8" optional and speakCON connector on a microphone stand. The most elegant solution for extending the low range of the hd C-Series models is the super slim hd Slim265 subwoofer. Thanks to its low height of only 102 mm, it fits into any false ceiling, can be mounted on a wall or placed invisibly under a piece of furniture. Main features Passive 2 1/2-way mini loudspeaker with 4 mid-woofers + a 3.5" coaxial speaker with 1" tweeter Works with any amplifier Integrated frequency and phase optimization Nominal dispersion: 80° x 80°  Precise and uniform sound radiation Weight: 4 kg

Technical characteristics

• Principle: coaxial loudspeaker
• Transducers: 4 x 3" woofer + 1 x 3.5″ and 1 x 1" tweeter coaxial speaker
• Crossover: 4 kHz
• Power handling: 190 W_RMS / 225 W peak
• Frequency response: 90 Hz – 22 kHz
• Sensitivity: 91 dB/W/m
• SPL max: 115 dB
• Nominal dispersion angle (H x V): 80° x 80°
• Nominal impedance: 8 ohm
• Enclosure: powder-coated aluminium profile black, steel grille with acoustic foam, clamping terminal inside, cable insert at the back, incl. 2 x M6 nuts
• Connections: 1 x clamp connection inside
• Options: speakON NL4, 3/8" thread + NL4, 35 mm flange + NL4, RAL color, special length, weather protection, 100 V transformer
• Dimensions: 10.8 x 46 x 10.4 cm
• Weight: 4 kg
