Wireless UHF True Diversity receiver UHF410-Base - AUDIOPHONY HIT-H10271

True Diversity UHF wireless receiver designed to ensure stable, interference-free transmission, ideal for professional audio applications. It operates on two frequency bands, 823 – 832 MHz and 863 – 865 MHz, compatible with crowded environments and 4G networks. It features 442 programmable frequencies with automatic scanning, divided into four groups of eight compatible channels each. Channel selection is via a touch button, automatic scanning, or SYNC synchronization.

Technical characteristics

• True Diversity receiver
• Frequency range: UHF 823 - 832 and 863 - 865 MHz
• 442 programmed frequencies with auto-scan function
• Channel presets: 4 groups, 8 compatible channels in each group
• Channel selection mode: Tact Switch, Auto-Scan, sync
• LCD display: frequency, group, channel, RF & AF
• Volume control by rotary switch on the front panel
• Squelch adjustment by rotary switch at the back
• Detachable BNC antennas, many accessories available
• Balanced and unbalanced audio output on XLR and 6.35 mono jack
• Line or microphone level
• Oscillator: PLL synthesizer
• Frequency stability: ± 0.005%
• Modulation mode: FM
• T.H.D.: < 1% (@ 1 kHz)
• Audio frequency response: 80 Hz - 18 kHz
• Power supply: 12 V_DC (adapter included)
• Current consumption: 260 mA ±10 mA
• Dimensions: 20 x 4.2 x 18.3 cm (rackable 19 inches by two)
