RJ45 wall controller for ZONEAMP4120 and PREZONE444 - AUDIOPHONY PA WP-1

Wall controller for ZONEAMP4120 and PREZONE444. Allows you to connect an external microphone or player to the selected channel. Direct access to the volume controls on the controller. Powered by the amplifier via RJ45.

Technical characteristics

• Inputs: 1 x XLR3-F MIC (front)
• 1 x RCA line (front)
• 1 x RJ45 output (rear)
• Volume settings on front panel
• ON/OFF switch
• LED VU meter
• 15 V_DC power supply via RJ45 cable from your ZONEAMP4120 or PREZONE444
• Operating range between WP-1 et the zone mixer: 200 m with category 6 cable
• Frequency response: 20 Hz - 20 kHz
• T.H.D. (1 kHz nominal power): < 0.1%
• Dimensions: 80 x 80 x 50 mm
• Weight: 0.2 kg
