Architectural flood light LED panel RGBL IP66 30° - CONTEST HIT-H11547

Contest VPANEL-200RGBL is a high-performance all-in-one architectural projector designed to enhance every detail with powerful, even illumination. Its source uses 24 LEDs rated at 20 W each, in red, green, blue and lime, delivering 6352 lumens and 1080 lux at 5 m. RGBL colour mixing extends the range available from conventional RGB: adding lime, or lemon yellow, produces additional shades, especially across yellow ranges that are traditionally difficult for RGB sources to reproduce.

Symmetrical 30° lenses with a double structure provide even beam distribution and emphasise architectural contours. DMX and power are connected through hybrid IN/OUT cables with IP67 connectors, simplifying simultaneous operation of multiple fixtures. The external VRDM control unit supports RDM parameterisation, while compatibility with RDM consoles applies to certain parameters. The DMX protocol provides 2 to 20 channels depending on the selected mode.

IP66 protection resists dust and water splashes from every direction. IK07 impact resistance protects against a 2-joule mechanical shock, corresponding to a 500 g object falling from a height of 40 cm. The unit uses convection cooling and a cast aluminium body with RAL 9002 white-grey epoxy paint. A sealed diaphragm depressurisation valve supports enclosure protection. The refresh rate can be selected from 900 to 3600 Hz. Despite its output, maximum power consumption is 207 W; LED technology uses less energy than traditional light sources and reduces operating costs. The power supply accepts 110 - 240 VAC at 50/60 Hz.
