Flat truss 290mm, flat corner coupler 4-way 90° - CONTESTAGE HIT-H10865

The Contestage H10865 is a 290 mm flat ladder truss with a 4-way flat corner joint and a 90° angle. It is made from EN AW 6082 T6 aluminium alloy, with 50 mm tubes, 2 mm thickness and 16 mm threads. The tube spacing is 240 mm, while the external dimension is 290 mm. Assembly uses a taper pin and key, and the conical connectors and pins allow fast setup and dismantling. ISO DIN 4113 and TÜV certified, it provides a safe, stable and resistant installation. The joint supports horizontal or vertical connections, with maximum dimensions of 50 cm x 50 cm. Suitable for stage structures, exhibition booths, concert and DJ stages, theatres, discos, lounges, gardens and outdoor events.
