Angular coupler 6-way 90° AGQUA-08 - CONTESTAGE HIT-H10060

The Contestage AGQUA-08 corner joint serves 290 mm square truss with six-way connectivity at a 90° angle. It is built from EN AW 6082 T6 aluminium alloy: 50 mm diameter tubes, 2 mm wall thickness, and 16 mm threads on the 50 mm tubes. The square section is 240 mm, with 240 mm centre-to-centre spacing between tubes and 290 mm outside dimension. Assembly uses a tapered pin and key sleeve; conical connectors and pins enable quick set-up and disassembly while ensuring a safe, stable and resistant installation. Manufactured in accordance with ISO DIN 4113 and TÜV certified.

Suitable for stage structures, exhibition booths, concert and DJ stages, theaters, discotheques, lounges, gardens and outdoor events.
