RGB 20000mW Purelight IP65 ShowNET laser system - Laserworld LAS-7640144998486

The PL-20 is a 20,000 mW Purelight series professional RGB laser system based on the new RSL2 technology, developed for a sharper beam, improved optical quality, and an extremely compact and lightweight enclosure. Thanks to its IP65 rating, the PL-20 is ideal for permanent outdoor installations, tours, and productions requiring maximum reliability even in harsh environmental conditions. The system uses high-performance 45 kpps @ 8° scanners with a maximum scanning angle of 50°, making it suitable for projecting professional graphics, logos, text, and complex effects. The beam has specifications of approximately 6.5 mm / 0.9 mrad, ensuring high visibility and precision. Each unit integrates the ShowNET mainboard, which allows control via DMX, Art-Net, LAN, ILDA, ILDA-Streaming, automatic mode, and Master/Slave. The internal memory allows for recalling preset patterns or custom content loaded in ILDA format. The device also includes a built-in display for quick configuration of operating modes. The PL-20 comes with a waterproof flight case and a full license for the Showeditor software, offering a professional workflow for creating and managing complex laser shows. User benefits RSL2 technology for superior optical quality Compact housing 20,000 mW RGB power 6.5 mm sharp beam with low divergence (0.9 mrad) 45 kpps professional scanners suitable for complex graphics IP65 rating Integrated ShowNET motherboard with DMX, Art-Net, LAN, ILDA, and ILDA Streaming control Internal memory for preset patterns and custom content Includes waterproof flight case and full Showeditor license Areas of use Permanent outdoor installations Clubs and large venues Touring Productions requiring high-power lasers Graphic projections, logos, and customized content Corporate events and multimedia shows Medium- and large-scale outdoor shows

Technical characteristics

• Guaranteed power at aperture: 20,000 mW
• Red output: 5500 mW / 638 nm
• Green output: 8000 mW / 520 nm
• Blue output: 9000 mW / 450 nm
• Beam specifications: ca. 6.5 mm / 0.9 mrad
• Scanner: 45 kpps @ 8°
• Max. scan angle: 50°
• Laser source: diode
• Laser class: 4

• Operation modes: ILDA, DMX, Art‑Net, LAN, ILDA streaming, integrated SD card, stand‑alone
• Basic patterns: over 120 (level, tunnel, grid, waves, etc.)
• Integrated control: ShowNET mainboard with built‑in DAC

• IP rating: 65
• Power supply: 85 V – 250 V_AC 50/60 Hz
• Power consumption: 280 W

• Dimensions (L x W x H): 36.5 x 23.4 x 23.2 cm
• Weight: 16 kg
• What's in the box:
  • Laserworld PL‑20
  • Waterproof flightcase
  • Power cable
  • Interlock
  • Key
  • Manual
  • Full version Showeditor software license
