BLACKMAGIC DESIGN

Acquisizione UltraStudio 4K Extreme 3 Thunderbolt 3 12G-SDI - Blackmagic Design BLM-BDLKULSR4KEXTR/3

Name: Acquisizione UltraStudio 4K Extreme 3 Thunderbolt 3 12G-SDI - Blackmagic Design BLM-BDLKULSR4KEXTR/3
Brand: BLACKMAGIC DESIGN
SKU: BLM-BDLKULSR4KEXTR/3
Price: 3337.80 EUR
Availability: OutOfStock

Non disponibileNuovo

SKU BLM-BDLKULSR4KEXTR/3EAN 9338716003857

Prezzo per 1 unità

3337,80 €

2735,90 € + IVA

Soluzione avanzata di acquisizione e riproduzione con Thunderbolt 3 a 40 Gb/s, connessioni 12G-SDI e HDMI 2.0 fino a 2160p60 con RGB 12 bit e HDR via HDMI 2.0a. Design rack con codifica H.265 in tempo reale tramite encoder hardware integrato.

Descrizione

UltraStudio 4K Extreme 3 rappresenta la soluzione di acquisizione e riproduzione più avanzata al mondo per computer con PCI Express e Thunderbolt. Dispone di Thunderbolt 3 a 40 Gb/s incredibilmente veloce, connessioni avanzate 12G-SDI e HDMI 2.0 per lavorare fino a 60 fps con colori profondi, RGB a 12 bit, supporto per flussi di lavoro HDR tramite HDMI 2.0a e dimensioni dei frame 4K estremamente grandi. La più ampia gamma di connessioni analogiche e digitali rende UltraStudio 4K Extreme 3 compatibile praticamente con qualsiasi telecamera, deck, router o display. Inoltre, è supportata la codifica H.265 in tempo reale, grazie al suo encoder hardware integrato estremamente potente. Caratteristiche principali Acquisizione e riproduzione Thunderbolt 3 in un design per rack Connessioni 12G-SDI, HDMI, analogiche Ideale per montaggio e correzione colore professionali SD, HD e Ultra HD fino al 2160p 60 4:2:2 e 4:4:4, acquisizione e riproduzione 3D dual stream

Specifiche tecniche

Aggiornamento software interno	firmware built into software driver. Software driver loads upgrades at system start or via updater software
Alimentazione	2 x built-in international AC power supply with IEC C14 inlet. 100 to 240 V, 50 to 60 Hz
Applicazioni software	DaVinci Resolve, Fusion, Final Cut Pro X, Adobe Premiere Pro CC, Avid Media Composer, Adobe After Effects CC, Avid Pro Tools, Steinberg Cubase, Steinberg Nuendo, Adobe Photoshop CC, OBS Studio, Wirecast, vMix Live, Zoom, The Foundry Nuke, Grass Valley Edi
Campionamento audio HDMI	48 kHz, 24 bit
Campionamento audio SDI	48 kHz, 24 bit
Campionamento video HDMI	4:4:4, 4:2:2, 4:2:0
Campionamento video SDI	4:2:2, 4:4:4
Codec supportati	AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, HEVC, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR, DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes 422 LT, Apple ProRes 422 Proxy, Uncom
Configurazione HDMI	HDMI 2.0b supports Deep Color and HDR. Automatically configures to connected display
Conformità SDI	SMPTE 259M, SMPTE 274M, SMPTE 292M, SMPTE 296M, SMPTE 372M, SMPTE 424M, SMPTE 425M, SMPTE 435, SMPTE 2048-1, SMPTE 2081-10, SMPTE 2081-11, SMPTE 2082-10, SMPTE ST2108-1, ITU-R BT.656, ITU-R BT.601
Ingressi audio AES/EBU	2 channels unbalanced with sample rate converter on BNC connector
Ingressi audio analogici	4 channels of professional balanced analog audio via XLR connectors and 2 channels of consumer unbalanced via RCA connectors
Ingressi audio HDMI	8 channels embedded in SD / HD / 4K
Ingressi audio SDI	16 channels embedded in SD / HD / 2K / 4K
Ingressi video analogici	1 x component YUV on 3 BNCs, 1 x composite NTSC/PAL on 1 BNC
Ingressi video HDMI	HDMI 2.0 type A connector with support for 2160p 60
Ingressi video SDI	2 x 12 Gb/s and 2 x 6 Gb/s SD / HD / 2K / 4K. Supports single, dual and quad link 4:2:2 and 4:4:4. 2D and 3D switchable
Ingresso MIC	1 x 48 V microphone input via XLR connector. Phantom power switchable via software control
Ingresso sync	1 x reference input. Tri-sync or black burst
Interfaccia computer	Thunderbolt 3 (Mac OS and Windows), PCIe 4 lane generation 2
Precisione del colore	8, 10, 12-bit RGB 4:4:4 up to 3840 x 2160p 30 and 8, 10-bit YUV 4:2:2 in all standards
Protezione dalla copia	HDMI input is unable to capture from copy protected HDMI sources. Always confirm copyright ownership before capture or distribution of content
Software incluso	DaVinci Resolve, Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux
Spazio colore HDMI	REC 601, REC 709, REC 2020
Spazio colore SDI	REC 601, REC 709, REC 2020
Standard video 2K	2048 x 1080p 23.98 DCI, 2048 x 1080p 24 DCI, 2048 x 1080p 25 DCI, 2048 x 1080p 29.97 DCI, 2048 x 1080p 30 DCI, 2048 x 1080p 47.95 DCI, 2048 x 1080p 48 DCI, 2048 x 1080p 50 DCI, 2048 x 1080p 59.94 DCI, 2048 x 1080p 60 DCI, 2048 x 1080PsF 23.98 DCI, 2048 x
Standard video 4K	4096 x 2160p 23.98 DCI, 4096 x 2160p 24 DCI, 4096 x 2160p 25 DCI, 4096 x 2160p 29.97 DCI, 4096 x 2160p 30 DCI, 4096 x 2160p 47.95 DCI, 4096 x 2160p 48 DCI, 4096 x 2160p 50 DCI, 4096 x 2160p 59.94 DCI, 4096 x 2160p 60 DCI
Standard video HD	720 x 480p 59.94, 720 x 576p 50, 1280 x 720p 50, 1280 x 720p 59.94, 1280 x 720p 60, 1920 x 1080p 23.98, 1920 x 1080p 24, 1920 x 1080p 25, 1920 x 1080p 29.97, 1920 x 1080p 30, 1920 x 1080p 47.95, 1920 x 1080p 48, 1920 x 1080p 50, 1920 x 1080p 59.94, 1920 x
Standard video SD	525i 59.94 NTSC, 625i 50 PAL
Standard video Ultra HD	3840 x 2160p 23.98, 3840 x 2160p 24, 3840 x 2160p 25, 3840 x 2160p 29.97, 3840 x 2160p 30, 3840 x 2160p 47.95, 3840 x 2160p 48, 3840 x 2160p 50, 3840 x 2160p 59.94, 3840 x 2160p 60
Supporto HDR	HDR metadata packing, HLG and PQ transfer characteristics
Supporto metadati SDI	RP-188/SMPTE 12M-2 and closed captioning
Supporto per frequenze multiple	HDMI and SDI video connections are switchable between SD, HD, UHD and 4K. Component analog video connections are switchable between SD and HD
Uscite audio analogiche	4 channels of professional balanced analog audio via XLR connectors
Uscite audio HDMI	8 channels embedded in SD / HD / 4K
Uscite audio SDI	16 channels embedded in SD / HD / 2K / 4K
Uscite video analogiche	1 x component YUV on 3 BNCs, 1 x composite NTSC/PAL on 1 BNC
Uscite video HDMI	HDMI 2.0 type A connector with support for 2160p 60
Uscite video SDI	2 x 12 Gb/s and 2 x 6 Gb/s SD / HD / 2K / 4K. Supports single, dual and quad link 4:2:2 and 4:4:4. 2D and 3D switchable
Velocità SDI	270 Mb/s, 1.5 Gb/s, 3 Gb/s, 6 Gb/s, 12 Gb/s
