Compact 4-channel mixer 2 mic Phantom 48V USB - AUDIOPHONY HIT-H10910

AUDIOPHONY HIT-H10910 puts four channels into a compact mixer, with two microphone inputs, two stereo inputs, an Aux send and USB connectivity. Each channel provides gain and AUX-level adjustment, while the mixer also includes two-band equalisation, MAIN, AUX, Record and monitoring outputs, plus LED level indication for the MAIN output.

Specifications:

• Configuration: 4-channel mixer, 2 microphone inputs, 2 stereo inputs, 1 Aux send and USB port.
• Microphone inputs: 2, via XLR plugs.
• Balanced line inputs: 2, on 6.35 mm jacks.
• Unbalanced stereo inputs: 2, on RCA and 3.5 mm jacks.
• Equaliser: 2-band EQ on MIC/line and stereo channels.
• Gain control: available on every channel.
• AUX level: adjustable on every channel.
• MAIN output: balanced, on a 6.35 mm jack.
• Record output: unbalanced, via RCA plugs.
• AUX output: balanced, on a 6.35 mm jack.
• Monitoring output: 6.35 mm stereo jack.
• USB: 1 port for connecting a computer; 2 USB ports with full duplex.
• Metering: LED VU-meter for the MAIN output.
• Declared inputs and outputs: MIC input 2, stereo input 2, Aux 1, stereo L/R output 2.
• Phantom power: +48 V DC.
• Gain: 65 dB, MIC main output.
• MIC channel EQ: ±15 dB; HI 12 kHz, LO 80 Hz.
• LINE channel EQ: ±15 dB; HI 12 kHz, LO 80 Hz.
• Frequency response: 20 Hz-20 kHz, ±1 dB.
• Maximum output level: +20 dBu.
• Meter: 4 segments, from -20 dB to CLIP.
• Distortion: ≤0.08%, 20 Hz-20 kHz.
• Power supply: 12 V DC external adaptor.
• Weight: 0.78 kg.
• Dimensions W x D x H: 220 x 160 x 68 mm.
