LFD digital signage 65" 4K UHD 400 cd/m² IPS 18/7 DICOM - PPDS PPD-65BDL3511Q/02

The 65BDL3511Q/02 is a 65-inch UHD 4K LFD designed for digital signage applications requiring reliability, easy setup, and continuous 18/7 operation. Direct LED backlighting ensures uniform light and a brightness of 400 cd/m2, ideal for standard indoor environments. The IPS panel offers wide viewing angles (178°) and consistent colors, while D-Image mode ensures optimized rendering for DICOM Part 14-compliant medical content. The FailOver function keeps content playback active at all times, automatically switching to a secondary source in the event of a problem, preventing black screens in critical situations. The integrated media player allows direct playback from USB via SmartPlayer, allowing you to program playlists without additional hardware. Remote management via CMND & Control simplifies the monitoring, configuration, and control of even very large display networks. Connectivity includes 3 x HDMI 2.0, DVI-I, and USB 2.0, audio inputs/outputs, and RS232 / RJ45 controls, with support for video wall configurations of up to 10 x 15 screens thanks to IR and RS232 loop-through. User benefits IPS panel for consistent colors and excellent readability from any angle Automatic failover, which ensures content continuity by avoiding black screens in the event of a source issue Integrated SmartPlayer, for playing playlists from USB without external media players Remote management via CMND & Control, with centralized network control, settings, and updates D-Image compatibility (DICOM Part 14) for non-diagnostic medical content Video wall support up to 10 x 15, ideal for large-format installations Areas of use Digital Signage Corporate: reception areas, meeting rooms, information areas, and internal communication Hotels, conference centers, common areas Information content and applications compatible with D-Image presets Museums, lobbies, shopping centers, transportation, and high-traffic areas Education: classrooms, auditoriums, internal signage, and campus communications

Technical characteristics

Picture / display

• Optimum resolution: 3840 x 2160 @ 60 Hz
• Panel resolution: 3840 x 2160
• Diagonal screen size: 64.5"
• Diagonal screen size (metric): 163.9 cm
• Brightness: 400 cd/m²
• Contrast ratio (typical): 1200:1
• Dynamic contrast ratio: 500,000:1
• Aspect ratio: 16:9
• Pixel pitch: 0.372 x 0.372 mm
• Response time (typical): 8 ms
• Viewing angle (horizontal): 178°
• Viewing angle (vertical): 178°
• Haze: 25%
• Display colours: 1.07 billion
• Panel technology: IPS
• Clinical image: D-Image preset (DICOM Part 14 compatible)

Supported display resolution

• Computer formats: 640 x 480 (60/67/72/75 Hz), 720 x 400 (70 Hz), 800 x 600 (56/60/72/75 Hz), 832 x 624 (75 Hz), 1024 x 768 (60/70/75 Hz), 1152 x 864 (75 Hz), 1152 x 870 (75 Hz), 1280 x 720 (60 Hz), 1280 x 800 (60 Hz), 1280 x 1024 (60 Hz), 1440 x 900 (60 Hz), 1600 x 1200 (60 Hz), 1680 x 1050 (60 Hz), 1920 x 1080 (60 Hz)
• Video formats: 480i @ 60 Hz, 480p @ 60 Hz, 576 @ 50 Hz, 576p @ 50 Hz, 720p @ 60 Hz, 1080i (50/60 Hz), 1080p (50/60 Hz), 3840 x 2160 (60 Hz)

Connectivity

• Video input: 3 x HDMI 2.0, 1 x DVI-I, 2 x USB 2.0
• Audio input: 3.5 mm jack
• Audio output: 3.5 mm jack
• External control: RJ45, RS232C (IN/OUT) 2.5 mm jack, IR (IN/OUT) 3.5 mm jack
• Signal loop through: RS232, IR loop through

Convenience

• Placement: landscape (18/7), portrait (18/7)
• Tiled matrix: up to 10 x 15
• Keyboard control: lockable, hidden
• Network controllable: RS232, RJ45
• Energy-saving functions: Smart Power
• Start-up options: switch-on delay, switch-on status, boot on source
• Start-up window: enable / disable
• Philips logo: enable / disable
• Ease of installation: Smart Insert

Sound

• Built-in speakers: 2 x 10 W RMS

Multimedia applications

• USB playback picture: BMP, JPEG, PNG
• USB playback video: H.264, JPEG, MPEG, WMV3
• USB playback audio: AAC, WMA, MPEG, HEAAC

Power

• Mains power: 100 – 240 V_AC 50/60 Hz
• Power consumption (typical): 165 W
• Power consumption (max.): 220 W
• Standby power consumption: < 0.5 W
• Energy label class: G
• Power saving features: Smart Power

Operating conditions

• Temperature range (operation): 0 to 40 °C
• Temperature range (storage): -20 to 60 °C
• Humidity range (operation): 20 to 80% RH (no condensation)
• Humidity range (storage): 5 to 95% RH (no condensation)
• Altitude: 0 - 3000 m
• MTBF: 50,000 hours

Dimensions

• Bezel width: 14.9 mm (even bezel)
• Wall mount: 400 x 400 mm, M8
• Dimensions (W x H x D): 1462.3 x 837.3 x 68.9 mm (wall mount) / 89.9 mm (handle)
• Product weight: 27.8 kg

What's in the box

• 65BDL3511Q/02
• AC power cord
• Remote control + AAA batteries
• Quick start guide
• AC switch cover
• IR sensor cable (1.8 m)
• RS232 daisy-chain cable
• USB cover + screw
• Philips logo
• 3 x wire clampers
