LFD digital signage 65" 4K UHD 500 cd/m² ADS panel Android 10 24/7 - PPDS PPD-65BDL4050Q/00

The 65BDL4050Q/00 is a 65" UHD 4K LFD designed for digital signage applications requiring high image quality, continuous 24/7 operation, and centralized management. Its 500 cd/m2 brightness and ADS panel ensure excellent visual performance, with uniform colors, wide viewing angles, and a low-reflection surface thanks to 25% haze. The embedded Android 10 operating system offers a stable and high-performance environment for running signage Apps, while the PPDS Wave platform allows remote control of the entire display network, with status monitoring, updates, and content management from a single interface. The FailOver function ensures operational continuity by automatically switching to an alternative source in the event of a problem, avoiding black screens. Installation is flexible in both landscape and portrait orientation, with support for video wall configurations of up to 3 x 3. Connectivity includes HDMI 2.0, USB 2.0/3.0, DVI-I, RS232, RJ45, and an OPS slot for additional modules. User benefits 24/7 operation, ideal for continuous installation in professional settings 500 cd/m2 brightness for excellent visibility in even moderately lit indoor environments Integrated Android 10, allowing Apps to run without external media players PPDS Wave for remote management, monitoring, and centralized updates Automatic failover to ensure content continuity in the event of source problems Flexible vertical or horizontal installation OPS slot to expand display functionality Areas of use Retail Corporate: reception areas, meeting rooms, information areas Hospitality: hotels, conference centers, common areas Airports, stations, travel hubs Foodservice Museums, shopping malls, lobbies, and information signage

Technical characteristics

Picture / display

• Format: 16:9
• Brightness: 500 cd/m²
• Contrast ratio (typical): 1200:1
• Dynamic contrast ratio: 500,000:1
• Diagonal screen size (metric): 163.9 cm
• Diagonal screen size (inches): 64.5"
• Optimum resolution: 3840 x 2160 @ 60 Hz
• Panel resolution: 3840 x 2160
• Panel technology: ADS
• Pixel pitch: 0.372 x 0.372 mm
• Viewing angle (horizontal): 178°
• Viewing angle (vertical): 178°
• Response time (typical): 8 ms
• Haze: 25%
• Display colours: 1.07 billion
• Picture enhancement: 3/2 - 2/2 pull-down, progressive scan, dynamic contrast enhancement
• Operating system: Android 10

Supported display resolution

• Video formats: 480i 60 Hz, 480p 60 Hz, 576i 50 Hz, 576p 50 Hz, 720p (50 / 60 Hz), 1080i (50 / 60 Hz), 1080p (50 / 60 Hz), 3840 x 2160 (30 / 60 Hz)
• Computer formats: 640 x 480 (60 / 67 / 75 Hz), 720 x 400 (70 Hz), 800 x 600 (60 Hz), 832 x 624 (75 Hz), 1024 x 768 (60 Hz), 1152 x 870 (75 Hz), 1280 x 720 (60 Hz), 1680 x 1050 (60 Hz), 1920 x 1080 (60 Hz), 3840 x 2160 (30 / 60 Hz)

Connectivity

• Video input: 2 x HDMI 2.0, 1 x DVI-I, 2 x USB 2.0, 1 x USB 3.0
• Audio input: 3.5 mm jack
• Audio output: 3.5 mm jack
• External control: RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack, RJ45
• Other connections: micro SD, OPS
• Signal loop through: RS232, IR loop through

Convenience

• Placement: landscape (24/7), portrait (24/7)
• Tiled matrix: up to 3 x 3
• Keyboard control: hidden, lockable
• Network controllable: RS232, RJ45
• Energy-saving functions: Smart Power
• Remote control signal: lockable
• Ease of installation: Smart Insert

Internal player

• CPU: Quad Core Cortex A55
• GPU: G52 MC1
• Memory: 16 GB, 3 GB DDR

Sound

• Built-in speakers: 2 x 10 W_RMS

Multimedia applications

• USB playback picture: JPEG, PNG, BMP, WEBP
• USB playback video: MPEG 1/2 (1080p 60 Hz), MPEG 4 (1080p 60 Hz), H.263 (1080p 60 Hz), H.264 (4K / 2K 60 Hz), H.265 (4K / 2K 60 Hz), VP8 (1080p 60 Hz), VP9 (4K / 2K 60 Hz)
• USB playback audio: AAC, HEAAC, MPEG 1/2/2.5 Layer 3, MPEG 1/2 Layer 1, MPEG 1/2 Layer 2

Power

• Mains power: 100 – 240 V_AC 50/60 Hz
• Standby power consumption: < 0.5 W
• Energy-saving features: Smart Power
• Energy consumption EEI Lot5: 77 W
• Energy label class: E

Operating conditions

• Temperature (operation): 0 to 40 °C
• Temperature (storage): -20 to 60 °C
• Humidity (operation): 20 to 80% RH (no condensation)
• Humidity (storage): 5 to 95% RH (no condensation)
• Altitude: 0 - 3000 m
• MTBF: 50,000 hours

Dimensions

• Bezel width: 14.9 mm (even bezel)
• Wall mount: 400 x 400 mm, M8
• Dimensions (W x H x D): 1462.3 x 837.3 x 68.9 mm (wall mount) / 89.9 mm (handle)
• Product weight: 28.5 kg

What's in the box

• 65BDL4050Q/00
• AC power cord
• Remote control + AAA batteries
• Quick start guide
• AC switch cover
• RS232 daisy-chain cable
• RS232 cable
• USB cover
• Philips logo
