Analog mixer 7-channel Bluetooth USB DSP TM 42 BU-DSP - Definitive Audio SOG-4910_TM_42BU_DSP

DEFINITIVE AUDIO

Analog mixer 7-channel Bluetooth USB DSP TM 42 BU-DSP - Definitive Audio SOG-4910_TM_42BU_DSP

In stock: 1New

SKU SOG-4910_TM_42BU_DSPEAN 3662279180288

Price for 1 unit

116,83 €

95,76 € + IVA

7-channel analog mixer, 2 Combo MIC / line inputs, stereo / mono jack input, stereo mini-jack LIVE input, SW FOOT input, 2 outputs, Bluetooth receiver and a USB player / recorder, LOW / HIGH EQ and high pass filter on channels 1-4, 99 effects DSP

Description

7-channel analog mixer, 4 Combo MIC / line inputs, stereo / mono jack input (CH 5-6), stereo mini-jack LIVE input (CH 7-8),  SW FOOT input for connecting a mute pedal. 2 male XLR outputs and 1 headphone output on 6.35 mm jack. It also features a Bluetooth receiver and a USB player / recorder. LOW / HIGH EQ and high pass filter on channels 1-4, 99 effects DSP (24 bit / 48 kHz). The microphone preamps are of high quality for flawless performance. Power supply: 5 VDC 2 A.

Technical characteristics

  • 7-channel mixer
  • Inputs: 4 XLR / jack Combos, 2 x 6.35 mm mono jacks, 1 x 3.5 mm LIVE mini-jack
  • USB MP3 / WAV / APE / FLAC player / recorder
  • Built-in Bluetooth receiver
  • DSP: 99 effects, 24 bit / 48 kHz
  • Outputs: 2 x XLR male and 1 x 6.35 mm headphones
  • 2-band EQ 80 Hz and 12 kHz ±15 dB
  • +48 V Phantom with LED indicator
  • LED saturation indicator
  • Low cut button
  • Stereo channel
  • SW FOOT input for plugging in a mute pedal
  • LED saturation indicator
  • Adjustable sensitivity
  • General level indicator: 2 x 6 LEDs (4 green, 2 yellow and 2 red)
  • Max output level: 3 VRMS
  • Frequency response 20 – 20,000 Hz ± 0.5 dB
  • Dynamics: 102 dB
  • THD: < 0.05%
  • Power supply: 5 VDC 2 A
  • Power consumption: max. 10 W
  • Dimensions: 232 x 182 x 65 mm
  • Weight: 1.38 kg


Specifications

Dimensions232 x 182 x 65 mm
DSP99 effects, 24 bit / 48 kHz
Dynamics102 dB
General level indicator2 x 6 LEDs (4 green, 2 yellow and 2 red)
Inputs4 XLR / jack Combos, 2 x 6.35 mm mono jacks, 1 x 3.5 mm LIVE mini-jack
Max output level3 V RMS
Outputs2 x XLR male and 1 x 6.35 mm headphones
Power consumptionmax. 10 W
Power supply5 V DC 2 A
THD≤ 0.05%
Weight1.38 kg
