Vertical colored flame machine 4 colors DMX powerCON - Showven SPK-FA03

SHOWVEN

Vertical colored flame machine 4 colors DMX powerCON - Showven SPK-FA03

Out of stockNew

SKU SPK-FA03

Price for 1 unit

7882,91 €

6461,40 € + IVA

1500 W vertical flame effect machine, four distinct systems to produce multi-colored flames up to 10 meters, DMX e 9 - 60 V Pyro signal

Description

cFlamer Quad is a vertical colored flame effect machine that integrates four distinct systems, allowing it to generate four different colored flames from a single nozzle.   Thanks to the preset sequences, it can create flames that change color, offering a unique effect. The machine is equipped with a water and corrosion resistant pump and pipe system, which allows the use of original SHOWVEN colored flame fluids or regular fluids such as ISOPAR and isopropanol.   The cFlamer Quad's flames can reach a maximum height of approximately 10 meters and has a fuel tank capacity of 2.5 liters for each system. It is controllable via 3 and 5-pin DMX and equipped with a Neutrik powerCON True1 interface, making it ideal for professional events and live shows. The structure is made of aluminum and 304 stainless steel, ensuring durability and resistance to the elements.   User benefits   The ability to generate four different colored flames adds incredible visual impact to events Versatility, thanks to the ability to use various types of fuel Reliable and safe use even in difficult conditions Aluminum and stainless steel body, resistant to adverse weather conditions E-stop system for maximum safety   Areas of use   Concerts and music festivals Corporate events and product presentations Ceremonies and weddings Fireworks shows Amusement parks TV and film productions

Technical characteristics

  • Input and power: 200 - 240 VAC 50/60 Hz, 1500 W
  • Housing material: aluminum + 304 stainless steel
  • Effect direction: vertical
  • Max. flame height (no wind): 10 m
  • Fuels: color fluid, ISOPAR L, ISOPROPANOL
  • Color additives optional: FX-red, green, blue, yellow, purple
  • Fuel tank capacity: 2.5 L * 4
  • Nozzle type: nozzle cH combo
  • Interface: Neutrik powerCON TRUE1 IN/OUT; waterproof 3-pin and 5-pin XLR IN/OUT
  • Control: DMX, 9 - 60 V Pyro signal
  • E-stop: yes
  • ARM indicator light: yes
  • Fuel filtration: yes
  • Ignition: high voltage electron ignition * 2
  • Valve: dual
  • Use in rain: yes
  • Dimensions: 58.5 x 41.9 x 33 cm
  • Weight: 51 kg

Specifications

ARM indicator lightyes
Color additives optionalFX-red, green, blue, yellow, purple
ControlDMX, 9 - 60 V pyro signal
Dimensions58.5 x 41.9 x 33 cm
E-stopyes
Effect directionvertical
Fuel filtrationyes
Fuel tank capacity2.5 L * 4
Fuelscolor fluid, isopar L, isopropanol
Housing materialaluminum + 304 stainless steel
Ignitionhigh voltage electron ignition * 2
Input and power200 - 240 V AC 50/60 Hz, 1500 W
InterfaceNeutrik powerCON TRUE1 IN/OUT; waterproof 3-pin and 5-pin XLR IN/OUT
Max. flame height (no wind)10 m
Nozzle typenozzle cH combo
Use in rainyes
Valvedual
Weight51 kg
