2-channel UHF wireless microphone set, 2 bodypack lavalier and headset microphones - RONDSON RON-02521-3

The RONDSON RON-02521-3 set includes two professional-quality UHF wireless bodypack microphones and a dual-channel UHF receiver fitted with selectable PLL frequency-synthesis receiving modules. Operating frequencies are 655 / 669 MHz. For each bodypack, BE-1000 and BE-2000 series wireless systems include one lavalier microphone and one headset microphone.

Automatic reception and anti-interference operation allow multiple units to work simultaneously. Operating range is 50 m, transmitter power is 10 mW and functions are shown on an LCD screen. The set is intended for professional vocal or audio applications, speeches, animation and similar uses. The package contains 1 jack cable for the mix output and 2 XLR cables.

This two-channel wireless bodypack microphone system uses a PLL synthesizer, easy-to-read LCD displays and a 50 m range in open areas. The BE-10HM is the lavalier microphone compatible with BE-10 and BE-20 sets, while the BE-10BP is the headset microphone compatible with the same sets. FM modulation has a frequency deviation of ±22 kHz, a 50 to 15,000 Hz frequency response and frequency stability of ±10 ppm. Interference rate is above 50 dB, S/N ratio is above 90 dB, sensitivity is -90 dBuV and distortion is below 0.5%.

Output impedance is 600 ohm and audio output level is -400 mV for balanced/unbalanced connections. Outputs comprise 2 x XLR-3M and 1 x 6.3 mm jack; antenna connections are 2 x BNC. The BE-1020 receiver measures 350 x 175 x 46 mm, is not rack-mountable, weighs 2.75 kg, requires 110 - 240 V DC 12 V 700 mA power and consumes less than 5 W.

BE-1020BP transmitters measure 58 x 18 x 100 mm, feature an XLR-3P connector and provide 10 mW RF power. Power is supplied by 2 x 1.5 V AA batteries, with consumption of 100 mA.
